Freestanding Sort Modules

Freestanding sort modules are designed to provide for maximum sorting capability in a minimal footprint. Available in 3 or 4 column configurations, widths between 36" - 56" and heights from 48" - 76". Supports standard, legal and oversize shelves.

Freestanding sort modules or literature racks are also available with base cabinets below for storage of packaging materials.

Specifications

• Sort shelves readjust along full depth rigid PVC plastic channel guides that
  allow for easy shelf adjustment.
• Adjustable Plastic Shelving: Constructed of 1/8” thick .90 gauge polyethylene
  with memory retention. Shelves are adjustable on 1” increments that provide
  full depth support. Shelves are supported front and rear with aluminum index
  track and clear index cover and are rated for capacity loads up to 35 lbs.
• Adjustable Wood Shelving: Constructed of 5/8” thick matching thermally fused
  melamine with 1.5mm PVC edge banding. Shelves are adjustable on 1”
  increments and have optional self-applying index strips. Shelves are rated for
  capacity loads up to 50 lbs.
• Freestanding Sort Modules (FSM) come in 3 or 4 column configurations.
  FSM’s with bottom storage areas and sliding reference shelves feature 7
  adjustable shelves providing 8 openings per column. All other FSM’s feature
  12 shelves per column providing 13 openings per column. Additional shelves
  can be purchased separately or in packs of five.
• FSM’s are available in widths of 36-7/16”, 42-7/16”, 48-1/8”, or 56-1/8” and heights of
  48”, 60”, 66”, 72” and 76”.
• FSM’s are with optional bottom storage area with or without sliding doors, pull
  out reference shelf or 12” kickplate.
• FSM’s are available in standard, legal or oversize configurations for standard 8-1/2 x 11 size documents, legal size documents and oversize documents like newspapers and periodicals.
• FSM Shelf Inside Dimensions:
  • Standard size shelf inside dimensions: 10-1/8” width x 12” depth
  • Legal size shelf inside dimensions: 10-1/8” width x 16” depth
  • Oversize shelf inside dimensions: 12-1/8” width x 16” depth

• Bottom storage are for Freestanding Modules:
  • FSM w/ Bottom Storage Inside Clearance
    Configuration Depth Height
    Standard Size 12” 15”
    Legal/Oversize 16” 15”
  • FSM w/ Sliding Reference Shelf Inside Clearance
    Configuration Depth Height
    Standard Size 12” 21-3/8”
    Legal/Oversize 16” 21-3/8”

Construction

• Side Panels: Constructed of 1” thick industrial grade 40-50 lb. sub-straight, double-faced melamine.
• Framed by matching 1.5mm PVC edge banding.
• Top and Bottom Panels: Constructed of 5/8” thick industrial grade 40-50 lb. sub-straight, double-faced melamine. Framed by matching 1.5mm PVC edge banding.
• Back Panel: Constructed of 5/8” thick industrial grade 40-50 lb. sub-straight, double-faced melamine.
• Vertical Dividers: Constructed of 5/8” thick industrial grade 40-50 lb. sub-straight, double-faced melamine. Framed by matching 1.5mm PVC edge banding.
• FSM’s are shipped fully assembled.
