Aluminum Framed Consoles

Aluminum framed consoles are designed to support sort modules, platforms and mailing machines. Framed in contoured anodized aluminum with high pressure laminate tops and available in widths of 24" - 84", heights of 30", 36", 42" and clearances of 3" or 9". Variations include open frame, half shelf, full shelf and cabinet consoles.

Table Styles:

• Half Inset Shelf
• Full Inset Shelf
• Vertical Partition
• Wheels/Dump Rim


Specifications

• All consoles come equipped with adjustable leveling guides to
  insure stable machine support on uneven floor environments.
• Aluminum framed consoles are available in the following
  configurations:
  • Basic (CT)- featuring open frame.
  • Half-Shelf (CH)- featuring a 15” or 18” deep half-shelf.
  • Full-Shelf (CS)- featuring a 30” or 36” deep full-shelf.
  • Cabinet (CC)- featuring a full-shelf and sliding doors
  • Center Mount Modesty (CX)- featuring a center mounted modesty panel designed to support additional weight.
• Consoles come in standard widths of 24” to 84”, depths of 24” to 36” and heights of 30”, 36” & 42”.
• Toe clearance options for consoles are available in 3” and 9”. Modifications are available to width, depth, height and clearance.
• All consoles are rated to support up to 750 lbs. Center Mount Modesty Consoles are rated to support up to 1,000 lbs.

Specialty Console Specifications

• All consoles come equipped with adjustable leveling guides to insure stable machine support on uneven floor environments.
• Specialty Consoles are available in the following configurations:
  • Manifest Shipping Consoles (MAN)- features a cabinet console with three grommets sold with a platform and articulating keyboard for supporting technology.
  • Crank Adjustable Consoles (CTxxxxxxADJ)- feature a Basic Console fitted with a crank adjustment that elevates the height of the table from 24” to 36”. Rated to support up to XX lbs.
  • Electric Adjustable Consoles (CTxxxxxxELE)- feature a Basic Console fitted with an electrical adjustment that elevates the height of the table from 24” to 36”. Rated to support up to XX lbs.
  • Adjustable Scale Consoles (SU)- features a Basic Console with a 6” drop down worksurface to make for more ergonomic mail weighing and metering. Worksurface can be readjusted up to 6” for various scale heights.
  • Console with Rollers (CR)- Basic Console fitted with 22” wide steel ball bearing rollers for package shuttle into Manifest Shipping Stations.
  • Shuttle Sort Systems (SS)- Includes a CT console with added support and mounted track, also includes three sort modules, two rear and one front, for additional sorting capacity.

Construction

• Leg units and supports are constructed of custom designed multi-cavity aluminum extrusions with a satin anodized finish and inlaid feature strips, optional aluminum finishes include silver-vein, coppervein and black powdercoat.
• Leg panels are constructed of 5/8” industrial grade, 40-50 lb. substrate double-faced melamine slotted into custom designed aluminum extrusions.
• Modesty panels are constructed of 3/8” industrial grade, 40-50 lb. substrate double-faced melamine.
• Undertable shelves are constructed of 5/8” industrial grade, 40-50 lb. substrate double-faced melamine framed with impact resistant 1.5mm PVC edgebanding.
• Sliding doors for undertable cabinets are constructed of 3/8” industrial grade, 40-50 lb. substrate double-faced melamine slotted into custom designed aluminum extrusions fitted with a nickel plated zinc alloy bow handle. Optional plunger locks available.
• Worksurfaces are constructed of 11/16” thick high-pressure laminate (HPL) with industrial grade 40-50 lb. substraight, backed with a .027 phenolic backer.
